HX711 Load Cell Weight Sensor Module with Digital Display
₹459.02 Inc. GST
Module size: 50x30x10mm
4-digit digital tube display
It can display up to 9999gm
Commonly used 5KG or 10KG pressure sensors can be connected.
Generally, the accuracy of the 5Kg range sensor fluctuates around 1g.
If the fluctuation is large, it may be caused by unstable power supply. Please replace the power supply and try it. (Calibration is required after the first connection)
Allow 1-2cm measuring deviation due to manual measurement.
Package includes: 1 x HX711 Load Cell AD Weight Sensor Module with Digital Display
The board is an integrated module of the pressure sensor test board, and there is no relevant information such as drawings and procedures. This is just a pressure sensor test board or pressure sensor display.
The module is designed for wide voltage, and the power supply range is DC 3-5.5V. There are 2 power supply methods. USB cable power supply or own wiring (reserved interface).
The module is connected to the pressure sensor first and then energized for use. After connecting with the pressure sensor for the first time, calibration is required. The board has functions such as peeling and calibration. The parameters can be saved after power-off, and there is no need to calibrate again in the future.
